The Goodman R-32 2.5 Ton 15.2 SEER2 Straight Cool Split System (GLXS4BA3010+AWST30LU13) is a powerful, energy-efficient split system HVAC for homes and businesses. With its reliable performance, compact design, and quiet operation, this system ensures consistent cooling even in the hottest months.

About the GLXS4BA3010 Condenser

The GLXS4BA3010 condenser is built for long-lasting performance and efficiency. It is ideal for medium-sized spaces with a nominal cooling capacity of 30,000 BTU/h.

Key Features

• Compressor: Single-stage rotary compressor provides efficient and reliable cooling.
• Noise Level: Operates at 71 dB for quieter performance.
• Motor: PSC motor with 1/6 horsepower ensures consistent airflow.
• Refrigerant: Utilizes R-32 refrigerant with a liquid line size of 3/8" and a suction line size of 3/4".
• Factory Charge: Comes pre-charged with 63 oz. of refrigerant.

Electrical Specifications

• Voltage/Phase: 208/230-1
• Minimum Circuit Ampacity (MCA): 15
• Maximum Overcurrent Protection (MOP): 25
• Voltage Range: 197 to 253 volts

Dimensions & Weight

• Width: 29"
• Depth: 29"
• Height: 32"
• Net Weight: 155 lbs.
• Gross Weight: 170 lbs.

About the AWST30LU1305 Front Return Air Handler

When paired with the condenser, the AWST30LU1305 air handler provides effective air distribution and additional comfort control. It ensures optimal indoor climate management with a nominal cooling capacity of 30,000 BTU/h and optional 5 kW electric heat.

Key Features

• Blower Type: Multi-speed ECM (MS-ECM) motor with 1/2 horsepower for enhanced efficiency and quiet operation.
• Full Load Amps: 3.8 amps for dependable energy consumption.
• Electric Heat: Supports 5 kW of supplemental electric heating for cooler days.
• Refrigerant Lines: Compatible with a 3/8" liquid and 3/4" suction lines.

Electrical Specifications

• Voltage/Phase: 208/230-1
• MCA: 26.4/29.8
• MOP: 30
• Voltage Range: 197 to 253 volts

Dimensions & Weight

• Width: 24"
• Depth: 21"
• Height: 36"
• Weight: 109 lbs.

Why Choose the Goodman R-32 2.5 Ton Split System?

1. Energy Efficiency: With a 15.2 SEER2 rating, this system delivers significant energy savings.
2. Reliable Performance: The single-stage rotary compressor and ECM blower motor provide consistent cooling and airflow.
3. Compact Design: Easy to install, even in areas with limited space.
4. Quiet Operation: Both components are engineered for minimal noise, enhancing indoor comfort.
5. Versatile Application: Ideal for residential homes, condos, and small commercial spaces.

Get the Goodman R-32 2.5 Ton Split System at Budget Air Supply

At Budget Air Supply & Equipment, we proudly offer the Goodman R-32 2.5 Ton 15.2 SEER2 Straight Cool-A/C Split System with Front Return Air Handler and a comprehensive selection of top-quality HVAC solutions. As a leading Florida-based wholesale HVAC supplier serving the continental United States, we provide competitive prices and exceptional customer service. Visit our website or contact us today to learn more about this Goodman system and how it can keep your space comfortable all year long.
